Product description

RedBack Lasers EL614 Electronic Rotating Laser Package with Tripod and Staff

Video Guides followed by Descriptions and Specifications







Description – Electronic Levelling Laser Package

The EL614 is a fully automatic levelling Electronic Rotating Laser Package with easy to use controls.  Simply place laser level on the tripod and press the power button, in seconds it self levels and begins to rotate.  The EL614 is extremely tough with steel internal chassis and heavy duty rubberised casing it can handle use day in, day out on the toughest of job sites.

The EL614 features TILT function in that if this is selected and the laser is disturbed or knocked the beam will stop rotating and indicate something has moved.  It also features V W S (vibration and wind setting) when selected the EL614 will continue to spin even when making minor adjustments due to vibrations, without it selected it will stop rotating each time to make those minor adjustments.

The EL614 comes complete with Heavy Duty LR715 electronic receiver with dual LCD displays front and back.  The EL614 also comes with rechargeable batteries and charger, but, can also be used with standard “C” batteries or even be powered of the charger/power supply.

Other brands sell rechargeable batteries and charger separately with the RedBack EL614 its all included.

The EL614 especially ideal for concreters who need a tough, reliable and accurate laser, also ideal for all general site levelling applications.

The RedBack EL614 comes with a 5 Year manufacturers warranty.

• Electronic Self Levelling
• Horizontal Rotation for Levelling
• Easy to Set Up and Use
• TILT and V-W-S Vibration modes
• Internal Steel Safety Cage
• Direct Drive Rotation
• INCLUDES Ni-mh Rechargeable Battery & Charger also Std “C” cell Battery Operation
• Heavy Duty Receiver
• 5 Year RedBack Warranty

includes Heavy Duty Tripod and 2.4m Staff Bundle (240HDF)

All RedBack Laser Levels have been Checked and Calibrated in Australia and come with a FREE certificate of calibration.

Specifications

• Range – 500m diameter using LR715 receiver
• Accuracy – +/- 1.5mm at 20m
• Laser Class – class 2 <1mW 635-670nm red
• Water Dust Resistance – IP55

Accessories featured in photos or video may be OPTIONAL, at an extra cost. Specifications may change without notice.

---
