RedBack Lasers EL614 Electronic Auto-Leveling Rotating Construction Laser Level Built Tough

Perfect rotary rotating laser level for Concreters, General Construction and Builders Site Levelling.

Video Guides followed by Descriptions and Specifications

Introducing the RedBack EL614 Auto-Leveling Rotating laser

VWS Vibration and Wind Function

TILT Function

EL614 Rotating Laser Level Description

RedBack Lasers EL614 is a fully automatic electronic self levelling rotating laser level with easy to use controls.  Simply place rotary laser on a tripod (optional extra) and press the power button, in seconds it self levels and begins to rotate.  The EL614 is extremely tough with steel internal chassis and heavy duty rubberised casing, in other words, it can handle rough treatment.  Is the perfect Construction, concreting and Agriculture laser.

Features

RedBack Lasers EL614 features TILT function in that if this is selected and the laser is disturbed or knocked the beam will stop rotating, therefore, indicating something has moved.  It will only re-start once you have selected to do so, thus, providing the opportunity to check that its still at the correct height.  It also features V W S (vibration and wind setting).  When selected the EL614 laser level will continue to rotate even when making minor adjustments due to vibrations.  Without it selected the laser will stop rotating each time to make those minor adjustments.  In high wind or near machines selecting VWS will make the levelling far quicker, because you no longer have to wait for it to start rotating again.

The EL614 rotating concreters laser level comes complete with Heavy Duty LR715 electronic long range receiver with dual, front and back, LCD displays.  A dual display is most important, in short, you can operate behind the receiver and not shade out the laser when reading it.  The EL614 also comes with rechargeable batteries and charger as standard, but, can also be used with regular alkaline “C” batteries or even be powered of the charger/power supply.

Other laser level brands rechargeable batteries and charger are not included and are sold separately! However, with the RedBack EL614 rotating laser level its all included.

The EL614 laser is perfect for concreters who need a tough, reliable and spot on accurate laser.  Therefore, this laser is also ideal for all general construction site levelling applications.

In Summary

The RedBack EL614 rotary laser comes with an automatic 5 Year manufacturers warranty, therefore, peace of mind.

  • Electronic Self Levelling
  • Horizontal Rotation for Levelling
  • Easy to Set Up and Use
  • TILT and V-W-S Vibration modes
  • Internal Steel Safety Cage
  • Direct Drive Rotation
  • INCLUDES Ni-mh Rechargeable Battery & Charger also Std “C” cell Battery Operation
  • Heavy Duty Receiver
  • 5 Year RedBack Warranty
All RedBack Laser Levels have been Checked and Calibrated in Australia and come with a FREE certificate of calibration.

Remember to add a tripod and Staff Bundle 240HDF if you need one.

Construction Rotating Laser Level Specifications

  • Long Range – 500m diameter using LR715 receiver
  • High Accuracy – +/- 1.5mm at 20m
  • Laser Class – class 2 <1mW 635-670nm red
  • Water Dust Resistance – IP55
Accessories featured in photos or video may be OPTIONAL, at an extra cost. Specifications may change without notice.



Compare this laser with similar models in our range!

Compare Specifications, Features, Accessories and more here!



TitleEL614 – RedBack Electronic Levelling Rotating Laser Level
Reviews
Price Original price was: $999.00.Current price is: $899.95. inc GST
Laser TypeRotating Laser
Horizontal LevellingAuto-Levelling - Electronic
Colour & Laser ClassRed - Class 2
Accuracy+/-1.5mm @ 20m
Range500m Diameter
ReceiverLR715 - Dual Display Receiver
Extra FeaturesTilt Mode, VWS Mode, Scan Mode
Grade SettingNo Grade Setting
Grade Range-
Vertical AlignmentNo
Mounting Options5/8" Survey Thread
BatteryNi-mh Rechargeable Battery, Battery Caddy - C Cell
CaseHard Case with Protective Foam
Warranty5 Years

in stock

or
TitleEL614S – RedBack Electronic Levelling Rotating Laser Level with Grade
Reviews
Price$1,099.00 inc GST
Laser TypeRotating Laser
Horizontal LevellingAuto-Levelling - Electronic
Colour & Laser ClassRed - Class 2
Accuracy+/-1.5mm @ 20m
Range500m Diameter
ReceiverLR715 - Dual Display Receiver
Extra FeaturesTilt Mode, VWS Mode, Scan Mode
Grade SettingSingle Grade, Manual Grade - Slope Remote
Grade Range+/- 8%
Vertical AlignmentNo
Mounting Options5/8" Survey Thread
BatteryNi-mh Rechargeable Battery, Battery Caddy - C Cell
CaseHard Case with Protective Foam
Warranty5 Years

in stock

or
TitleEL614GM – RedBack Electronic Levelling Auto Grade Match Rotating Laser with mm Display Tracking Receiver
Reviews
Price Original price was: $1,499.00.Current price is: $1,349.95. inc GST
Laser TypeRotating Laser
Horizontal LevellingAuto-Levelling - Electronic
Colour & Laser ClassRed - Class 2
Accuracy+/-1.5mm @ 20m
Range600m Diameter
ReceiverLR720T - mm Tracking Receiver
Extra FeaturesTilt Mode, VWS Mode, Scan Mode
Grade SettingSingle Grade, Auto-Grade Match to mm Receiver, Manual Grade - Slope Remote
Grade Range+/- 8%
Vertical AlignmentNo
Mounting Options5/8" Survey Thread
BatteryNi-mh Rechargeable Battery, Battery Caddy - C Cell
CaseHard Case with Protective Foam
Warranty5 Years

in stock

or
TitleBASIC614 – RedBack Electronic Levelling Rotating Laser Level
Reviews
Price$799.00 inc GST
Laser TypeRotating Laser
Horizontal LevellingAuto-Levelling - Electronic
Colour & Laser ClassRed - Class 2
Accuracy+/-1.5mm @ 20m
Range500m Diameter
ReceiverLR715 - Dual Display Receiver
Extra FeaturesTilt Mode, VWS Mode, Scan Mode
Grade SettingNo Grade Setting
Grade Range-
Vertical AlignmentNo
Mounting Options5/8" Survey Thread
BatteryBattery Caddy - C Cell, Optional Rechargeable Battery
CaseSoft Case with Protective Foam
Warranty5 Years

in stock

or



FREE Freight Australia Wide
Have a Question?
Call 1800 769 858





RedBack Lasers service department also service and calibrate the following brands when possible; Topcon RL-H5B, Leica, Rugby, Geo Fennel, Spectra, Imex, Powerline, Spot on, Tuf, Bosch, Dewalt, Laser Tec, General, Hilti, PLS, Fukuda, Stabila, Stanley, sokkia,

Weight6 kg
Dimensions37 × 45 × 25 cm

DOWNLOADS

Instruction PDF can be viewed, printed and downloaded HERE



Range Brochure PDF can be viewed, printed and downloaded HERE
