Earthmoving implements like blades and buckets on skid steers, posi-tracks, loaders, and tractors — provided the implement has its own hydraulic valve bank on the blade. Dozer buckets and similar can't be automated.

Earthmoving Specialists · 25 Years

Machine Automation — Set, automate, finish.

Automated height control and laser guidance for blades, buckets and earthmoving implements. Single and dual hydraulic ram systems, customisable to skid steers, posi-tracks, loaders and tractors. Built and tailored in Australia for real site conditions.

Shop automation systems Call 1800 769 858

RedBack laser automation system fitted to a skid-steer blade on a worksite

1 or 2Hydraulic rams — single or dual ram automation systems

CustomTailored systems built and configured for your machine

ManualReceiver-only options for cabin readings without auto-control

Step One

Laser Automation Systems

RedBack’s automation systems give a smooth, accurate finish trim by reading a rotating laser beam and driving your blade hydraulics to match it. Single-ram for skid steer blades and land planes; dual-ram for blades that need independent left/right height control.

Each kit includes the receiver(s), control box and cables as listed. Most setups need a hydraulic expert and an auto-electrician to integrate cleanly with your machine — we’ll work with you to spec and tailor a system to your blade and hydraulic valve setup. Call 1800 769 858 for a tailored quote.

MCR900 Single Receiver Machine Control System earthmoving automation system

Machine Automation System MCR900 - RedBack Laser Machine Control System with Single Receiver and Hydraulic Control Unit $4,180.00inc GST View →

Laser Machine Control System for Dual Receivers MCR910 esrthmoving automation system

Machine Automation System MCR910 - RedBack Laser Machine Control System with Dual Receivers and Hydraulic Control Unit $10,000.00inc GST View →

Watch

Machine automation in action

Real footage from skid steers, posi-tracks and graders running RedBack laser automation. Pick a video on the right to play it — start with the intro for context, then jump to single-ram or dual-ram demos.

Step Two

A rotary laser to drive it

Every laser automation system needs a rotating laser to give the receivers a beam to track. Pair your control system with one of these long-range, high-accuracy rotary & grade lasers — all with mm display receivers and Class 3 power for big sites.

10% Off

NEW! mm Receiver

Rotating LaserNEW! mm Receiver

EL614S

Rated 5.00 out of 5 based on 1 customer rating

Accuracy +/- 1.5mm @ 20m

Range 700m Diameter

Horizontal

0.5mm Receiver (80mm Long)

Ni-mh Rechargeable

Single Grade

10% Off

NEW! mm Receiver

Rotating LaserNEW! mm Receiver

EL614SP

Rated 5.00 out of 5 based on 3 customer ratings

Accuracy +/- 1.5mm @ 20m

Range 700m Diameter

Horizontal

0.5mm Receiver (80mm Long)

Ni-mh Rechargeable

Single Grade

Rotating Laser

EGL624

Accuracy +/- 1.5mm @ 20m

Range 600m Diameter

Horizontal & Vertical

Dual Display Receiver

Ni-mh Rechargeable

Dual Grade

10% Off

Rotating Laser

EGL624P

Rated 5.00 out of 5 based on 2 customer ratings

Accuracy +/- 1.5mm @ 20m

Range 600m Diameter

Horizontal & Vertical

Dual Display Receiver

Ni-mh Rechargeable

Dual Grade

Not Ready to Automate?

Manual machine receivers

If full automation isn’t on the cards yet, machine-mounted receivers give you a clear, large-display height reading from the cab — magnetic or clamp mount, with or without an in-cab readout. Same accuracy, manual control of the blade.

10% Off

Machine Receiver

MR706

Rated 5.00 out of 5 based on 4 customer ratings

Sensor 250mm Long

Versatility

Magnet Mount

360° Sensors

2 Accuracy Settings

40Hr Rechargeable Battery

10% Off

Machine Receiver

MR708

Rated 5.00 out of 5 based on 1 customer rating

Sensor 250mm Long

Versatility

Clamp Mount

360° Sensors

2 Accuracy Settings

40Hr Rechargeable Battery

10% Off

Machine Receiver

MR706D

Rated 5.00 out of 5 based on 3 customer ratings

Sensor 250mm Long

Versatility

Magnet Mount

Wired In-Cab Display (10m Cable)

360° Sensors

2 Accuracy Settings

40Hr Rechargeable Battery

10% Off

Machine Receiver

MR708D

Sensor 250mm Long

Versatility

Clamp Mount

Wired In-Cab Display (10m Cable)

360° Sensors

2 Accuracy Settings

40Hr Rechargeable Battery

FAQ

Machine Automation Questions

What is laser automation?

Laser automation does the height adjustment of your blade automatically for you. Receivers detect the height of your laser level’s beam, and the control box drives the hydraulics of your blade to match it — giving a smooth final finish or trim of a pad without manual input.

What’s the difference between Single and Dual automation?

Single systems control one hydraulic ram. Dual systems control two rams independently. Single is good for small skid steer blades or land planes where one ram controls the whole height. Dual is better when you have two rams controlling each side of a blade — more precise height control across the length of the blade and more responsive for single or dual grades.

My blade has a tilt function — can this work with your system?

Out of the box, no — but we can custom wire a joystick or wiring loom to allow you to control the tilt function alongside the height controls. Call us to talk through your setup.

What can I automate?

Earthmoving implements like blades and buckets attached to skid steers, posi-tracks, loaders, tractors, etc. The implement needs its own hydraulic valve bank on the blade itself — so dozer buckets and similar can’t be automated. Some blades are easier than others — call 1800 769 858 to verify if our laser automation will suit your machine.

What comes in the automation systems?

The automation systems listed include the receiver(s), control box and cables as standard. You can buy this and have your local auto-electrician set it up, and we’d recommend engaging a hydraulic expert to ensure the blade has the necessary valves. Most setups need more than the base kit to get running, so we tailor custom systems to suit. Call 1800 769 858 for a quote — customising a system isn’t always quick, so allow time for build and testing before shipping.

Can I still manually control my blade?

Yes. Automation is purely designed for the final trim, so for most of your bulk cut and fill you’ll likely still be manually controlling the blade anyway.

Real support. Real people.

Need a system tailored to your machine?

Customising an automation system isn’t a one-size-fits-all job. Talk to the specialists — 25 years of laser automation experience on the other end of the phone.
