Green Multi-Line Laser With Servo Electronic Self Levelling & Auto Tracking Base

The XLG44AT is a green multi-line laser with auto-tracking base and servo electronic self-levelling. The laser features ultra-bright green laser lines ideal for interior fit-out and installation applications. The helpful LED display on the laser indicates which lines are selected. With all lines turned on you have a massive 360-degree horizontal line coverage, 4x vertical lines producing ceiling cross and 4 wall crosses. Plus a floor plumb red dot for floor to ceiling transposing of points.

Servo Electronic Self Levelling

Electronic Servo levelling means fast, accurate and durable self-levelling. The XLG44 360G Green automatically self-levels continuously — for minor adjustments using the rotation fine adjust knobs the laser will stay illuminated. This makes vertical alignment far easier than other servo multi-line models. With the control panel you can select a variety of lines to suit your needs. The bright LCD display provides a simple way to see which lines have been selected.

The laser is operated by simply pressing the red power button. The "V" and "H" buttons select the number of horizontal or vertical laser lines activated. The "M" mode button toggles between "P" Pulse mode for use with the included green line receiver, and "D" is a power-saving dimmer mode. The XLG44AT comes supplied with two Li-ion battery packs so one can be charging while the other is in use. There is also a backup "AA" battery holder.

An additional feature unique to this laser is an integrated laser dot on the front horizontal and vertical lines. These dots are more intense than the lines themselves, making the location of the lines easier in very bright conditions.

Auto Tracking Base

This special XLG44AT kit includes the AT1 Auto Track motorised base and tracking line receiver. The Auto TRACK is designed to make vertical laser line alignment and square as easy as possible — featuring an auto-tracking line receiver that communicates with the motorised base unit. The kit operates with any red or green beam line laser with either a 5/8" survey thread or 1/4" camera thread mount.

Auto Tracking for Auto Square

Place the laser on the base unit and set the laser into pulse mode. Place the receiver on its side at the target location and line up the yellow vertical line to the precise point you want to align to. With a few simple button presses on the receiver, the motorised base will rotate and auto-track to the receiver location. Once the receiver picks up the laser line it will communicate back to the base unit and lock on when perfectly aligned.

When using the XLG44 with its verticals at 90 degrees to each other you can simply produce an auto site square for layout. This system can be used for both indoor and outdoor applications. The carry case is designed to hold both the laser and the Auto Track Base with all accessories.
