LLR805MM
mm Display Line Laser Receiver for Green & Red Line Lasers (50mm Display)
- Take your Line Laser outdoors with maximum precision!
- mm Display 25mm above & below level
- Suits Red & Green Line Lasers with Pulse Mode
- Large 100mm Detection Window
Some accessories shown are optional extras. See what's included
Out of stock — get notified
Leave your details and we'll let you know the moment it's back.
In stock now: similar alternatives
- Free delivery Australia-wide. Dispatched fast from our warehouse.
- 1 year warranty.
- Talk to a laser specialist. Call 1800 769 858 or .
Overview
RedBack Lasers new & improved mm Line Receiver. Easily detect your Line Laser in outdoor or bright conditions where Lines are invisible. Featuring a massive 100mm Detection window with mm Display 25mm Above & Below level for maximum precision.
RedBack Lasers LLR805MM – our best Line Laser Receiver yet!
Improved Responsiveness. Use your Line Laser anywhere.
RedBack Lasers’ LLR805MM is our new & improved design of Line Laser Receiver technology. Designed with performance in mind, we’ve improved the responsiveness of the line laser receiver from previous generations – so you can spend more time building & less time measuring!

1 Laser to suit Indoor & Outdoor use!
In days gone by, choosing a laser level for outdoors was simple – you grab a rotating laser.
Although rotating lasers are great for levels & heights and offer long range – they usually lack the ability to easily give alignment (straight lines) or squares which is something Line Lasers do well indoors.
Nowadays – the choice is harder – as Line Lasers when paired with a receiver like the LLR805MM allow for easy outdoor use – giving the similar functionality as a Rotating Laser (although over a shorter distance) like levels while also offering Alignment & Square – all at once! Then if you need to do any indoor work – you have a bright line laser for any tiling, installation, fit-out, set-out or similar applications.
mm Display – what makes it so good?
99% of Line Laser Receivers on the market feature incremental arrows up & down to indicate the position of the laser.
mm Receivers take the guesswork out of it – telling you exactly where you are vs. where you need to be.
A mm Display Receiver will make you more precise – a lot of receivers from big name brands having a 3mm tolerance built into the level band. The LLR805MM will tell you exactly when you are within 0mm, 1mm, 2mm etc. – so you can be as accurate as required.
It will also speed up your workflow – as you’ll know exactly how much you need to cut/fill or how far you need to move left/right in a second rather than trying to guess when relying purely on arrows.

Key Features
- mm Display Receiver for Red & Green Line Lasers with Pulse Mode
- Allows Line Lasers to be used outdoors/in bright conditions where the beam is not visible
- New Line Laser Receiver features improved responsiveness
- 25mm Display Above & Below Receiver for Precision
- 100mm Long Sensor Window
- Dual Sided Displays
- Loud Audible Speaker
- Backlit LCD Display
- Adjustable Accuracy Settings
- Near & Far Mode
- Comes complete with Adjustable Staff Bracket
What's Included
- LLR805MM Line Laser Receiver
- SB720 Adjustable Staff Bracket
- Batteries for Receiver
Full Specifications
| Compatible lasers | Line lasers with pulse mode |
|---|---|
| Sensor Length | 100mm Long |
| mm Display | 50mm (25 Above & Below level) |
|---|---|
| Range | Up to 150m Radius (Laser Dependent) |
